GE LOGIQ P6 Series User Manual

GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Chapter 3 - Page 3-15
Section 3-6System Configuration
3-6-1 System Specifications
3-6-1-1 System Settings
1.) Press Insert key on the A/N keyboard to enter the utility menu.
2.) Select Utility > System > General.
3.) Set the Hospital name, Department, Date and Time, Language, and Units.
4.) Click on Exit to terminate the utility function.
Table 3-1 System Configuration
Configuration Category Description
Settings
Enables the user or service personnel to set the
date, time, unit, language, basic information about
the organization such as the institution name and
department.
Figure 3-12 Setting Display

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
