GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 3-2 Section 3-1 - Overview
Section 3-2Installation Reminders
3-2-1 Average Installation Time
The LOGIQ™ P6/P6 Pro has been designed to be installed and checked out by an experienced service
technician in approximately four hours. LOGIQ™ P6/P6 Pro consoles with optional equipment may take
slightly longer.
3-2-2 Installation Warnings
1.) Since the LOGIQ™ P6/P6 Pro weighs approximately 80 kg.(176 lb.) without options, preferably two
people should unpack it. Two people are also preferable for installing any additional bulky items.
2.) There are no operator serviceable components. To prevent shock, do not remove any covers or
panels. Should problems or malfunctions occur, unplug the power cord. Only qualified service
personnel should carry out servicing and troubleshooting.
NOTE: For information regarding packing labels, refer to LABELS ON PACKAGE.
3.) After being transported, the unit may be very cold or hot. If this is the case, allow the unit to
acclimate before you turn it on. It requires one hour for each 2.5×C increment it's temperature is
below 10×C or above 30×C.
Table 3-2 Average Installation Time
Description Average Installation Time Comments
Unpacking the scanner
0.5 hour
Scanner wo/options
0.5 hour
Dependant on the configuration that is required
DICOM Option
0.5 hour
Dependant on the amount of configuration
InSite Option
0.5 hour
CAUTION
Equipment damage possibility. Turning the system on without acclimation after arriving at site
may cause the system to be damaged.
Table 3-3 Acclimation Time
°C
60 55 50 45 40 35 30 25 20 15 10 5 0 -5 -10 -15 -20 -25 -30 -35 -40
°F
140 131 122 113 104 96 86 77 68 59 50 41 32 23 14 5 -4 -13 -22 -31 -40
hrs
864200000002468101214161820
