GE LOGIQ P6 Series User Manual

GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Chapter 8 - Page 8-103
8-2-47-2 How to read Serial No
1.) Check checkboxes of system boards you want to read or System Serial No checkbox.
NOTE: You can read System Serial No, L2SYSCON board, DTRX64II_L board, DTRX64II_R board,
PI128II board and CWD board information.
8-2-47-3 How to write info on the system
1.) Check checkboxes of system boards you want to write or System Serial No checkbox.
2.) Put the Serial No, Part No, or Rev on the black box.
3.) Press “Write” Button.
Figure 8-152 Reading System Info

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
