GE HEALTHCARE

DIRECTION 5394152, Revision 5

LOGIQ™ P6/P6 PRO SERVICE MANUAL

Chapter 8 - Page 8-189

8-7-17 Protect Cover Installation

1.) Install the prtective covers in rear and front as shown in Figure 8-312 using the double side adhesive

tape.

Figure 8-312 Protect Cover Installation

Double side adhesive tape
