GE HEALTHCARE

DIRECTION 5394152, Revision 5

LOGIQ™ P6/P6 PRO SERVICE MANUAL

Page 8-188 Section 8-7 - Mechanical Option Installation instruction

8-7-16 Additional Task Lamp installation (cont’d)

4.) Install task lamp bracket to the rear side of keyboard by screwing 2 screws(5178673, FH M4x6

WHT).

5.) Fix the task lamp light as shown on the figure below.

6.) Install BW hide bracket if it is uninstalled during the installation process.

Figure 8-309 Additional Task Lamp Installation

Figure 8-310 Additional Task Lamp Installation

Figure 8-311 Additional Task Lamp Installation
