GE HEALTHCARE

DIRECTION 5394152, Revision 5

LOGIQ™ P6/P6 PRO SERVICE MANUAL

Page 7-26 Section 7-1 - Overview

7-8-5 APS II Assy

The APS Assy is located at the No. 5 slot of the NEST Assy.

Table 7-14 LEDs on APS II Assy

LED

Descriptions Normal State

DP5 (Top) Digital 5V output indicator Normally On

LP5 Live Power 5V output indicator Normally On

AP6 Analog 6V output indicator Normally On

DP33 Digital 3.3V output indicator Normally On

SHV+ SHV+ output indicator status indicator Normally On

HVL+ HVL+ level indicator Normally On in CFM mode or PW mode

HVH+ (Bottom) HVH+ level indicator Normally On in B mode
