GE HEALTHCARE

DIRECTION 5394152, Revision 5

LOGIQ™ P6/P6 PRO SERVICE MANUAL

Page 8-142 Section 8-4 - Software Installation

8-5-4 Restore procedure

1.) From Figure 8-140, press “Restore” button.

2.) Rest of the procedure is the same with “Backup” procedure.

3.) After reboot,

Press “Patient”. Verify that Patient data are restored.

Press “Utility”. Verify that Userdefined data are restored.

NOTICE

The system should be rebooted after finishing of Restore procedures.
