LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 3-4 Section 3-1 - Overview
Section 3-3
Receiving and Unpacking the Equipment
When a new system arrives, check that any components are not damaged and are not in short supply.
If shipping damage or shortage occurs, contact the address shown in Chapter 1.
1.) Cut the four PLASTIC BANDs.
Figure 3-2 Cutting the Plastic Bands.
CAUTION
Do not lift the unit by the Keyboard. Equipment damage may result.
CAUTION
The crate with the LOGIQ™ P6/P6 Pro weighs approximately 80 Kg (176 lb.). Be prepared for a
sudden shift of weight as the unit is removed from its base (pallet)
Plastic Bands

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
