LOGIQ™ P6/P6 PRO SERVICE MANUAL

Chapter 3 - Page 3-5

Section 3-3 Receiving and Unpacking the Equipment (cont’d)

2.) Lift the TOP COVER up and off.

Figure 3-3 Removing the top Cover

Top Cover
