GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 7-30 Section 7-1 - Overview
7-9-3 System Does Not Boot (cont’d)
Figure 7-16 System does not Boot (contd.)
System doesn’t boot! (cont’d)
1.) Check the Control
Panel cable
connection.
2.) Check/replace
Control Panel.
YES
YES
NO
Are the Control Panel
keys lit?
Is regular scan display
shown on the monitor?
Press and hold the main switch for
five (5) seconds to reboot the
system.
NO
Go to Scan Procedure section.
END

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
