GE LOGIQ P6 Series User Manual

GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Chapter 5 - Page 5-41
5-9-2 Enabling MRFS (cont’d)
All the fields that are marked with asterisk * are mandatory and should be filled
6.) When fields with asterisk are filled, “Add User” button is enabled.
7.) Press “Add User” button.
8.) check the checkbox next to the name to set to the default contact. Then Press “Set Default Machine
Contact” button,
9.) Now the MRFS is enabled.
10.)When system detects high temperature or abnormal voltage, the system will send the RFS to the
OLC automatically.
Figure 5-45 Add User
Figure 5-46 Set Default Machine contact

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
