LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 1-6 Section 1-1 - Overview
“OFF/Standby” Indicates the power off/
standby position of the power switch.
CAUTION
This Power Switch DOES NOT ISOLATE
Mains Supply
Adjacent to On-Off/Standby Switch
“Mains ON” Indicates the power on position of
the mains power switch.
“ON” Indicates the power on position of the
power switch.
CAUTION
This Power Switch DOES NOT ISOLATE
Mains Supply
Front Panel Switch
“Protective Earth” Indicates the protective
earth (grounding) terminal.
Internal
Indicates an earth GROUND potential
Product schematics
Peripherals
Table 1-5 Product Icons
LABEL/SYMBOL PURPOSE/MEANING LOCATION

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
