GE LOGIQ P6 Series User Manual

GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Chapter 1 - Page 1-15
1-3-5 Label Locations (cont’d)
1.) Possible Shock Hazard
2.) Label -”Do not use the following devices near this equipment.”
3.) Label - “The equipment weighs approximately 80kg.
4.) Prescription Devices
5.) CE Mark Label (Left), WEEE Label (Right)
6.) CISPR Label
7.) Ground reliability Label
8.) Voltage Range Indication and Power indication Label
9.) LCD Caution Label
10.)LCD Arm Rotation Label
Figure 1-2 OUTSIDE MARKINGS OF LOGIQ™ P6/P6 Pro

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
