GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 9-10 Section 9-6 - NEST
Section 9-6 NEST (cont’d)
Item Part Name FRU Number Description Qty FRU R1.0.x R2.0.x~ R3.0.x~
401 PI128 II Assy 5327228
Probe Connection
Board
1 1 Yes Yes Yes
402
DTRX64II Assy 5252321-2
64Ch TX/RX
Beamforming Board
1 1 Yes Yes Yes
BT11 DTRX64II Assy 5399198
64Ch TX/RX
Beamforming Board
1 1 Yes Yes Yes
403 CWD64 Assy 5245003
64Ch Continuos Wave
Doppler Board
1 1 Yes Yes Yes
404 SYSCONML Assy (with SOM) 5252326-2
Main Control & BEP
Board
1 1 Yes Yes Yes
405 APS II Assy 5245004
DC Voltage Power
Supply
1 1 Yes Yes Yes
406 DualCore SOM 5252327-2 PC module 1 1 Yes Yes Yes
407 RFC Assy 5252324
128Ch TX/RX Signal
Connection Board
1 1 Yes Yes Yes
408 BP128 Assy 5252320 Backplane Board 1 1 Yes Yes Yes
409 P6 Nest FAN Assy 5252349 FAN assy for Nest Box 1 1 Yes Yes Yes
410 P6 TRANS FAN Assy 5252350 FAN assy for TransBox 1 1 Yes Yes Yes
411 DTRX Cooler with heatsink 5252351
FAN cooler in
DTRX64II
21Yes
412 SYSCON Base 5270805-2 1 1 Yes Yes Yes
413 LP6 CW Doppler kit 5269166 1 1 Yes Yes Yes
414 P3RLY assy 5144579-2 LP6 BT09 Pro Only 1 1 Yes Yes
415 RFC PRO Assy 5266433 LP6 BT09 Pro Only 1 1 Yes Yes
Table 9-5 NEST
