GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 10-22 Section 10-6 - Electrical Safety Tests
7.) Record the patient lead to ground leakage current measured on the data sheet.
8.) Set the meter's “FUNCTION” switch to LEAD TO LEAD position to measure the lead to lead leakage
current.
9.) Select and test each ECG lead positions (except ALL) of the LEAD selector, testing each to the
power condition combinations.
10.)Record the lead to lead leakage current measured on the data sheet.
11.)Set the meter's “FUNCTION” switch to LEAD ISO position to measure the patient lead isolation
current.
12.)Select and test each ECG lead positions (except ALL) of the LEAD selector, testing each to the
power condition combinations.
13.)Depress the rocker switch to ISO TEST and read the isolation current. To apply the voltage to the
lead safely, the voltage is only applied when the rocker switch is depressed to ISO TEST.
14.)Record the patient lead isolation current measured on the data sheet.
ON REVERSE OPEN
OFF NORM CLOSED
OFF NORM OPEN
OFF REVERSE CLOSED
OFF REVERSE OPEN
Table 10-19 Testing Power Conditions
ECG Power Meter’s Polarity Switch Meter’s Neutral Switch

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
