GE Revolution CT - Reformat Planning; Automatic Reformat; Semi-Automatic Reformat

When the button is in this state: The reformat is in this state: Clicking the button does this:
Auto-Run You are prescribing the reformat task. If the button is grayed out, select the
appropriate protocol from the Protocol
section.
Click the button to autorun the refor‐
mat after recon data has been ac‐
quired.
Run
The recon data is available, but the re‐
format has not been run.
Click the button to run the reformat.
This button is grayed out if you have
not selected a protocol or defined a
batch reformat manually, or an Auto
Batch has been run.
3.2 Reformat planning
3.2.1 Automatic reformat
For an automatic reformat, no images are acquired before planning the reformat.
1.
From the Reconstruction and Image Processing Task List, click the down arrow on the
series you want to reformat.
2. Select the protocol you want to use from the Reformat Settings panel.
3. Check the Auto Run box in the lower right of the window to enable auto run. DMPR images
will be generated automatically.
3.2.2 Semi-automatic reformat
1. From the Reconstruction and Image Processing Task List, click the down arrow on the
series you want to reformat.
2. Select the protocol you want to use from the Reformat Settings panel. Adjust the settings for
the protocol. Auto Run is not selected.
3. After the source images have been reconstructed, select the reformat task.
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
428 3 Direct Multi Planar Reformat (DMPR)
