The recorded median heart rate is more than 30 BPM from the current real-time heart rate
average.
•
The heart rate range/variability measured is greater than 40 BPM.
•
There is no breath hold recording is present.
•
When there is an alert set in the profile.
See
Automatically record the heart rate during breath hold
.
See
Manually record the heart rate during breath hold
.
5.2 Auto Gating Configuration window
1.
From the image monitor, click .
2.
Click
Protocol Management
, then
Auto Gating Configuration
.
The
Auto Gating Configuration
window allows you to configure acquisition settings based on the
patient's heart rate and variation. The bottom half of the window lets you define scan settings for
the selected Heart Rate and HR Rhythm categories in the top half of the window.
NOTE:
The heart rate range supported is 30-200 BPM.
Illustration 14: Auto Gating Configuration Window
Revolution CT User Manual
Direction 5480385-1EN, Revision 1
Chapter 13 Cardiac 357
