Stress Echo analysis
Vivid S70 / S60 – User Manual 7-17
BC092760-1EN 01
Figure 7-7. Image selection from the Protocol screen
Manual selection of images in the Analysis screen
1. When currently in protocol analysis in the Stress analysis
screen (Figure 7-8), hold down Shift while selecting the
images from the stress template matrix in the lower right
corner of the screen.
Manual selection of images in the Protocol screen
1. In a stress examination, press Protocol.
A preview of the acquisitions is displayed.
2. Trackball to the first image to select.
3. Press Select.
The frame of the selected loop is highlighted.
4. Repeat steps 2 and 3 to select other images.
5. Press Analyze to open images in the Analyze screen (see
page 7-18).
NOTE: Alternative: Double click on the last selected image to open
images.
1. Select a Projection
2. Select an image
3. Select and open an Image
group
