Advanced cardiac measurements and analysis
Vivid S70 / S60 – User Manual 8-47
BC092760-1EN 01
NOTE: The tracing algorithm uses the QRS trig points from the
ECG, and will run analysis on all full heart cycles displayed
on screen.
3. The Sensitivity rotary can be adjusted to align the
automated trace as needed. Parameters in the list can be
toggled on/off.
NOTE: The Sensitivity changes apply only for non-rejected cycles.
Review and Approve
4. When hovering over a cycle, the cycle can be rejected or
exclusively kept by clicking the corresponding symbol to
reject or keep. Press the Recalc button to restore rejected
cycles.
