Measurements and Analysis
8-48 Vivid S70 / S60 – User Manual
BC092760-1EN
01
NOTE: When hovering over a specific cycle, the measurements will
reflect only that specific cycle, indicated by the number of
the cycle.
5. Press Store when satisfied with all the displayed cycles.
Results
6. After Store is pressed, the results for each cycle are split
into separate measurements and displayed as seen below.
The Cardiac AutoDoppler measurements use computer
algorithms for envelope detection and recognition of points
of interest. There is an inherent risk that these algorithms
may sometimes give suboptimal or incorrect results. Verify
the correctness of the displayed points and traces before
approving them.
