4D/Multi-plane LV
Vivid S70 / S60 – User Manual 8-57
BC092760-1EN 01
Contour adjustment
The contour detection should be checked. If the contour
detection is not optimal, it can be adjusted by adding attracting
points to the contour. An attracting point will pull the contour
toward that point.
1. Place the cursor at the location where to add a point.
NOTE: Attracting points can be added in any slice. Make sure to
lock the interactive view if adding attractive points in the
interactive view.
2. Press Select.
A point is added and the contour is modified (Figure 8-29).
3. To delete an attracting point, double click on the point or
press Undo.
Figure 8-29. Contour adjustment
a. Original contour b. Modified contour
1. Original attracting points 2. Added attracting point
