Customize Configuration
12-26 Vivid S70 / S60 – User Manual
BC092760-1EN
01
3. Double-click (Name) and enter the name for the formula
(e.g. My LIMP).
4. Select .
The Edit formula window is displayed.
Figure 12-15. The Edit formula window
5. Select “(“ from the Operators drop-down menu.
6. In the Doppler drop-down list, select
MCO [My Folder, MCO].
Make sure to select the measurement located in the
user-defined folder (e.g. “My Folder”).
7. Select “-“ from the Operators drop-down menu.
8. In the Doppler drop-down list, select
AV ET [My Folder, AVET].
9. Select “)“ from the Operators drop-down menu.
10. Select “/“ from the Operators drop-down menu.
NOTE: Operators may also be entered using the alphanumeric
keyboard.
11. In the Doppler drop-down list, select
AV ET [My Folder, AVET].
The Formula line should display: ({MCO}-{AVET})/{AVET}.
No units are necessary since the formula is a ratio (‘About
units’ on page 12-29).
12. Press Check to make sure that the syntax for the formula is
correct.
