Customize Configuration
12-34 Vivid S70 / S60 – User Manual
BC092760-1EN
01
• Measure Name: type the name of measurement that
will display in the Measurement menu (e.g. My BPD
Measure).
• Author Name: Type the author’s name (e.g. My Name).
• Table Type: If necessary, select the table type (e.g.
Fetal Age).
• Measure type: select the desired measurement (e.g.
BPD).
7. Select Edit table.
The OB Table spreadsheet is displayed, showing the table
template selected.
8. Enter the Min, Max and Interval values in the Parameters
field.
The system automatically fills in the MEAS column.
9. Enter the input values for the MEAN and SD columns.
10. Select Exit to save.
The OB table templates
Template 1 (based on Hadlock)
Fetal age format: MEAS MEAN SD
Unit: mm week week
Table range: 1 SD
Graph range: 1 SD
Measurement
result
Value: [cm]
GA: [#w#d]
Min: [#w#d]
Max: [#w#d]
Fetal growth Format: AGE MEAN SD
Unit: week mm week
Others are same as above
Template 2 (based on Tokyo)
Fetal age Format: MEAS MEAN SD
Unit: mm day day
Table range: 1 SD
Graph range: 1 SD
