Connectivity configuration
Vivid S70 / S60 – User Manual 12-55
BC092760-1EN 01
4. Click the Wireless Settings button - see Figure 12-37.
Figure 12-38. Wireless Settings Main Screen
NOTE: If a wireless network adapter is not connected, or if the
connected wireless network adapter is not the correct
model, no wireless networks will be listed in the Wireless
Settings page.
5. Either double-click or select the network you want to
connect to, and press the Connect button.
If this is the first time you attempt to connect to the network,
a dialog will pop up on screen asking you to configure the
network setting.
Figure 12-39. First Time Connection Dialog
6. Press OK in the dialog window. A new window for setting up
your connection will open.
