Archive
Vivid S70 / S60 – User Manual 12-67
BC092760-1EN 01
Image settings Definition
Raw Data Settings Raw Data Settings gives you the ability to select which images to
transfer in raw data format by mode:
• All images
• Apical 2D (auto classified)
• Parasternal 2D (auto classified)
• 2D/Biplane/Triplane
• M-mode
• Colorflow/TVI/Biplane/Triplane
• Color M-mode
• PW/CW
• 4D
• 4D Color
Raw Compression Enables compression of raw data images upon storage and export. Raw
compression is active only if the setting Allow raw data is checked.
Max Frame rate Select 25, 30 or Full (original acquisition) from the pop-up menu.
Compression Select compression type or no compression.
Quality Set picture quality from 1 to 100%. A low picture quality level allows high
data compression, while a high picture quality restrains the
compression.
Allow Multiframe
: Allow cineloop storage.
Systole only (for Stress) When this setting is active, all stress images will be sent to the DICOM
server showing only systole. The setting is selectable when transferring
only multiframe (not raw data).
Connection settings Definition
Retry Set maximum number of connection retries, time interval between
tentative and time-out.
DICOM settings Definition
AE Title The Application Entity Title is set during DICOM configuration. Refer to
the network specifications.
Port The Port no. is allocated during DICOM configuration. Refer to your
network specifications.
Verification Verify the connection to another DICOM application.
Storage commitment Send a request to a PACS, asking it to permanently archive image(s).
MPPS Modality Perform Procedure Step: send information (typically to a HIS)
that a scheduled exam has been started, performed or interrupted.
