Application Presets List
Vivid S70 / S60 – User Manual 12-93
BC092760-1EN 01
NOTE: This removes the preset from the list but does not delete the
preset from the Preset config. page.
4. Select Move and touch a new position to move the selected
preset to a new position on the list.
5. Press Done to exit the Preset config page.
To modify additional settings for the selected application
In addition to the various imaging settings for the different
scanning modes, other settings can be stored for each user
preset. These can be found on the Application preset config
page:
1. Activate the probe and application-preset to be modified.
2. Pres Utility/Config and log on if required.
3. Select Imaging/Application.
The Application preset config page appears.
The following settings can be configured on this page:
Parameter Description
Image Store settings Single frame (live store):
• : Store cineloop
• : Store single frame image only
Auto freeze
• Freeze 2D image in Doppler: the last 2D or
color flow image is displayed when entering
Doppler mode.
• Auto freeze after: sets the time after which the
system enters in freeze when not in use.
Footswitch functionality Configure the footswitch pedals. For each pedal,
select the operation to perform from the drop-down
menu when in Live or in Freeze.
Show indicator on screen: when selected, the
assigned controls for the pedals are displayed on
screen.
Templates and Packages Defines the default stress protocol associated to
the application.
Auto invert on steer
In Color flow, the color bar is inverted when
steering the color flow sector angle.
Keep cursor when pressing 2D
Keep cursor when changing mode
The PW, CW or M-Mode cursor is kept on the 2D
display when pressing 2D on the Control panel.
