Customize Configuration
12-92 Vivid S70 / S60 – User Manual
BC092760-1EN
01
Figure 12-69. User preset
Updating a user preset
1. Activate the Probe Selection screen and select a preset.
2. Modify the settings for image parameters.
3. Press the Preset Config button of the selected probe.
4. Press Save/Create.
A window appears with the name of the current preset.
5. Press Save to update the preset or edit the name and then
press Save to generate a new preset.
To arrange the list of application presets
1. Touch the Preset Config button at the bottom of the column
of the requested probe.
The Preset Config page appears (Figure 12-70).
Figure 12-70. Preset config page
2. Touch any preset.
A preset configuration menu appears (Figure 12-67).
3. Select Remove from list to clear the checkbox and remove
this preset from the preset list.
