Biopsy
Vivid S70 / S60 – User Manual 13-49
BC092760-1EN 01
Figure 13-14. The biopsy brackets
2. Orient the bracket so that the needle clip attachment is on
the same side as the probe orientation mark, see
Figure 13-15.
3. Attach the biopsy bracket to the probe by sliding the bracket
over the end of the probe until it clicks or locks into place.
Make sure the bracket is firmly attached to the probe.
11L-D
M5Sc-D
(Vivid S70 only)
3Sc-RS
C1-5-D
Probe Biopsy bracket
