Site requirements
Vivid S70 / S60 – User Manual 3-7
BC092760-1EN 01
To help ensure grounding reliability, connect to a "hospitalgrade"
or "hospital only" grounded power outlet.
Figure 3-3. Example Plug and Outlet Configurations
Battery
The System contains an internal battery (optional), which is not
user-accessible. The internal battery acts as a limited alternative
power source, which becomes active when the AC power fails or
AC cable is abruptly pulled out.
Display turns off and no scanning is possible while in battery
mode.
Battery technology
The lithium ion technology used in the system’s battery is
significantly less hazardous to the environment than the lithium
metal technology used in some other batteries (such as watch
Ensure that the retaining clamp for the power plug is fixed
firmly.
Use caution to ensure that the power cable does not
disconnect during system use. If the system is accidentally
unplugged and the optional battery is not installed, data may be
lost.
To avoid risk of fire, the system power must be supplied from a
separate, properly rated outlet.
Under no circumstances should the AC power plug be altered,
changed, or adapted to a configuration rated less than
specified. Never use an extension cord or adapter plug.
1. 100-120 VAC, 1200 VA Plug and Outlet Configuration
2. 220-240 VAC, 1200 VA Plug and Outlet Configuration
