3.4.1.1 During a normal boot, you may observe
1.
Power is distributed to peripherals, control console, monitor, FrontEnd and BackEnd processor.
2. The BackEnd processor and rest of the system starts with the sequence listed in following steps:
a. First of all, the BIOS version is shown on the monitor.
b. Afterward the “Boot Screen” is displayed. (Voluson is highlighted).
Figure 3-4 Boot screen
3. BackEnd processor is turned ON and starts to load the software.
4.
The start screen is displayed on the monitor.
5. Start-up progress bars indicating software loading procedures, are displayed on the monitor.
Figure 3-5 start-up screen
6. The software initiates and sets up the FrontEnd electronics and the rest of the system (incl. clicking
sound of relays on RTF board).
7. The keyboard backlight is lit.
8. As soon as the software has been loaded, the 2D screen is displayed on the monitor.
EC320/EC330 (BT17/BT18) only:
1.
If patient data stored on the internal HDDs D:\ partition are encrypted (protected), the system has to be
unlocked by Password, Recovery key or USB device with unlock key.
For further details refer to
Section 3.7.1.13.2 "Unlock an encrypted Disk" on page 3-47
.
2. If
Activate User Login
is check marked in the
Setup - General Settings - Authentication
page, a system
login window appears. Please enter the proper
User Name
and
Password
and then click
Login
.
Setup Instructions
Voluson E-Series Service Manual
5539550APB Revision 6
3-11
