GS corpuls3 - Advanced Settings (Persons Responsible for the Device)

User Manual corpuls
3
Configuration
ENG - Version 2.1 – P/N 04130.2 147
Field Setting Values Incre-
ments
12-lead ECG 12-lead ECG printout Enabled, disabled –
Rep. cycle
Printout of the
representative cycle
Enabled, disabled –
Global info Printout of diagnosis Enabled, disabled –
Speed
Sweep speed of the D-
ECG
25 mm/s, 50 mm/s –
ECG Format Printout format
2 x 6 –
4 x 3 –
Duration
Duration/length of the
printout of one ECG block
3 to 10 s 1 s
Order
Classic placement of ECG
curves or according to
Cabrera
Classic,
Cabrera
–
Add. copy Prints out another copy Enabled, disabled –
Measuring table
(option)
Adds the measuring table
of interpretation to the
printout
Enabled, disabled –
Suggestion
(option)
Adds a therapy
suggestion to the printout
Enabled, disabled –
Table
7-4 Values for the D-ECG printout
2. To have the 12 lead ECG included in the protocol, tick the checkbox "12-
chan. ECG" in the group "Format".
3. To display the representative cycle, tick the checkbox "Rep. cycle" in the
group "Format".
4. Select the D-ECG speed on the printout.
5. Select the printout format:
2 x 6: Two blocks of six ECG leads each are printed.
4 x 3: Four blocks of three ECG leads each are printed.
6. Select the duration of the ECG block.
7. Select the order of the ECG curves on the D-ECG printout:
Classic: Leads I, II, III, aVR, aVL, aVF.
Cabrera: Leads aVL, I, -aVR, II, aVF, III.
8. To print out an additional copy of the D-ECG, tick the checkbox "Add. copy".
9. Optional: Add the measuring table of interpretation to the printout.
10. Optional: Add the therapy suggestion to the printout.
To confirm the settings and close the configuration dialogue, press the softkey
[OK].
To retain the previous settings and close the configuration dialogue, press the
softkey [Cancel].
