Procedure in case of malfunctions
ENG - Version 2.1 – P/N 04130.2 243
Alarm message Priority Explanation/Measure
No ECG cable
(PACER)
High priority  The pacer is stimulating in DEMAND mode, but
there is no 4-pole ECG cable connected or individual
ECG electrodes are loose.
 Check if the 4-pole ECG cable is connected correctly
to the patient box.
 Check ECG electrodes.
 Make sure that all clips are correctly connected to
the contacts and/or the ECG electrodes are perfectly
placed on the patient’s skin.
No GSM PIN
configured
Low priority  The PIN belonging to the SIM card has not been
configured.
 Configure the PIN.
No Oxi adhesive sensor
No adh. Oxi sen. (P-
Box)
Medium priority  The adhesive sensor is defective or has expired.
 The sensor LED's have to be aligned directly over
each other at the measuring site.
No Oxi sensor
Medium priority  The sensor cable is not connected or not connected
correctly.
 Disconnect sensor cable and connect again.
 If the sensor LED does not flash, the sensor has to
be exchanged.
No SIM card
Low priority  The SIM card is missing.
 The SIM card is not correctly inserted in the drawer
of the monitoring unit.
 Insert the SIM card in the drawer in the monitoring
unit.
ONLY FOR TEST
PURPOSE
ONLY FOR TESTS (P-
Box)
High priority  The software of the module has been released only
for test purposes. Using this module on a patient is
prohibited.
 Contact authorised sales and service partners.
Oxi adhes. sensor
expired
Adh. Oxi sen. exp. (P-
Box)
Medium priority  The adhesive sensor is defective or has expired.
 The sensor LED's have to be aligned directly over
each other at the measuring site.
Oxi cable expired
Oxi cable exp. (P-Box)
Medium priority  The intermediate cable is expired and has to be
exchanged with a new one.
Oxi cable loose Medium priority  The cable indicated is not connected to the patient
box.
 Check the respective cable and reconnect if
necessary.
Oxi failure (X)
Oxi failure (X) (P-Box)
Medium priority  „X“ stands for a failure number from 1 to 10.
 The measuring option mentioned is faulty.
 Contact authorised sales and service partners.
