GS corpuls3 - Appendix; Symbols

Procedure in case of malfunctions User Manual corpuls
3
260 ENG - Version 2.1 – P/N 04130.2
Malfunction Troubleshooting Explanation/corrective action
A nasal oxygen cannula not
authorised by Nihon-
Kohden is used.

If oxygen is administered from an
undesirable direction via a non-authorised
O
2
cannula it may affect the expiratory
CO
2
.
 Use an authorised nasal oxygen cannula
(e.g. oxygen cannula “V923”, Nihon-
Kohden, P/N MKD-02-capONE).
 For further authorised oxygen cannulae
contakt the manufacturer Nihon-Kohden
(www.nihonkohden.com) or an corpuls
sales and service partner.
Nasal oxygen cannula
comes off easily
Nasal oxygen cannula is
not attached to the patient.
The oxygen cannula must be attached with
surgical tape for stable measurement.
 A nasal oxygen cannula
not authorised by Nihon-
Kohden is used.
 The nasal oxygen
cannula might not be
firmly attached to the
nasal adapter.

Use an authorised nasal oxygen cannula
(e.g. oxygen cannula “V923”, Nihon-
Kohden, P/N MKD-02-capONE).
 For further authorised oxygen cannulae
contakt the manufacturer Nihon-Kohden
(www.nihonkohden.com) or an corpuls
sales and service partner.
Table
10-9 Malfunctions during CO
2
monitoring
Malfunction Possible cause Measure
The temperature value
is not displayed.
The temperature sensor is
not connected to the patient
box.
Make sure that the plug of the temperature
sensor is connected to one of the two
sockets "Temp1" or "Temp2".
No signal data is received.
The connection to the
patient box is possibly cut
off.

Check the connection status and reduce
the distance between the monitoring unit
and the patient box if necessary.
 If this error occurs when operating as
compact device, check the infrared
interfaces.
 If necessary, contact sales and service
partners.
The temperature value
appears implausible.
The temperature sensor is
faulty.
Replace the temperature sensor with a new
one.
Table
10-10 Malfunctions during temperature monitoring
Malfunction Possible cause Measure

The invasive
pressure values are
not displayed.
 The invasive
pressure curve is not
displayed.
The pressure recorder
(transducer) cable is not
connected to the patient
box.
Make sure that the cable of the pressure
recorder is connected to one of the two
sockets "IBP1" or "IBP2".
No signal data is received.
The connection to the
patient box is possibly cut
off.
Check the connection status and reduce
the distance between the monitoring unit
and patient box if necessary.
