User Manual corpuls
3
Appendix
ENG - Version 2.1 – P/N 04130.2 287
Energy management/power supply
Internal power supply
Modules with exchangeable, chargeable battery
(lithium-ion battery)
Each module with identical lithium-ion battery
Battery capacity 4.4 Ah at 7.4 V nominal voltage (each)
Battery size
(H x W x D in cm)
4.2 x 4.6 x 7.6 [1.7 x 1.8 x 3 inches]
Battery weight (in kg) 0.25 [0.55 lbs]
Charge current, max.
per battery
3 A
Output current, max.
per battery
• 4.4 A (continuous operation)
• 10 A (for 10 sec)
External power supply Valid input voltage
range
Min 10 V, typ. 12 V, max. 14 V
Protection of the on-
board power supply,
12 V
15 A, time lag fuse
(additional consumers on-board not taken
into account)
AC adapter
corpuls
3
Output power, max. 108 W
Nominal voltage 12 V
Output current, max. 9 A
Classification by protection type against electrical shock when
operated via mains charger (according to IEC 60601-1):
Protection class I
Power consumption (typically,
compact device)
Thermal power
dissipation (device
operation)
20 W
Max. Power
consumption (device
operation and battery
charging)
100 W
Max. Power
consumption (device
operation and
charging of
defibrillator, 5 sec
max.)
108 W
Battery charging time 0 - 80%
0 – 90%
0 - 100%
approx. 1 h
approx. 1.5 h
approx. 2 h
