Display
Description/explanation
Type 8.4’’ colour display,
transflective with 750 Cd/m
2
backlighting
Screen size, visible Width 171 mm, height 128 mm
Screen definition 640 pixels horizontal, 480 pixel vertical, VGA
Angle of view Horizontally: 160°
Vertically: 140°
Backlighting Lifetime approx. 15,000 h
Sweep speed

ECG, Pleth, IBP curve: 12.5; 25; 50 mm/s
 CO
2
curve: 3,13; 6.25; 12.5 mm/s
Curves

Up to 6 simultaneous curves
 In diagnostic ECG mode 12 simultaneous curves
Measurements All measured values can be displayed on the screen
Table A
-11 Display
Printer
Description/explanation
Printing method High definition thermo printer head
Print definition

8 pixels/mm (amplitude axis)
 16 pixels/mm (time axis) with 25 mm/s
Paper speed

Real-time printout: 6.25; 12.5; 25 and 50 mm/s
 Diagnostic ECG: 25 mm/s and 50 mm/s
Number of curves for real-time
printout
1 to max. 6 curves simultaneously
Printing paper

Thermo active, roll
 Width 106 mm, length 22 m
Table A
-12 Printer
ECG
Description/explanation
Amplifier input Type CF, insulated > 5 kV, defibrillation proof
Frequency response 0.05 to 150 Hz (-3 dB)
Driving-point impedance
> 100 MΩ
Common mode rejection (CMRR) 4-pole ECG monitoring cable and complementary 6 pole ECG
diagnostic cable: > 90 dB
Dynamic range
± 350 mV (signal voltage) (12 Bit)
Max. electrode offset voltage
± 350 mV (input offset)
Scanning frequency 500 Hz
Digital definition
3.2 µV/bit
