User Manual corpuls
3
Appendix
ENG - Version 2.1 – P/N 04130.2 299
Description/explanation
Sensor weight (without cable) < 10 g
Protection IP54
Diameter of the connector of
airway adapter
15 mm
Accuracy (based on an
atmospheric pressure of 1 mmHg
and without CO
2
in the inhaling
phase)
± 4 mmHg (≤ 40 mmHg)
± 10% of reading value (40 mmHg < CO
2
≤ 76 mmHg)
± 12% of reading value (76 mmHg < CO
2
≤ 100 mmHg)
Accuracy (based on an
atmospheric pressure of 0.13 kPa
and without CO
2
in the inhaling
phase)
± 0.53 kPa (≤ 5.33 kPa)
± 10 % of reading value (5.33 kPa < CO
2
≤ 10.13 kPa)
± 12 % of reading value (10.13 kPa < COtttt
2
≤ 100 kPa)
Air humidity during storage 10 to 95%, non-condensating
-29 Capnometer (Option CO
2
, manufacturer Nihon Kohden, cap-ONE)
Deviations due to negative effects of gases and steam (acc. to ISO 9918:93/ EN 864:1996
§101)
Gas or steam Concentration Deviation relative to a measured
CO
2
value of 38 mmHg
Oxygen (O
2
) 100% - 1.3 mmHg
Nitrous oxide (N
2
O) 80% + 6.5 mmHg
Halothane 4% + 0.6 mmHg
Enflurane 5% + 1.5 mmHg
Isoflurane 5% + 1.7 mmHg
Sevoflurane 6% + 2.7 mmHg
Desflurane 24% + 6.6 mmHg
Dry gas mixtures with 5% (38 mmHg) CO
2
and N
2
compensation, under 1 kPA
Table A-30 Deviations due to negative effects of gases and steam
Caution!
Only use the recommended sensors and adapters. Any accessories other than those
itemised in the ‘list of approved accessories’ (see chapter 9.8 Approved Accessories,
Spare Parts and Consumables, p. 224) are not permitted.
Certification of biocompatibility according to ISO 10993-1 is required.
