Appendix
User Manual corpuls
3
298 ENG - Version 2.1 – P/N 04130.2
Description/explanation
Measurement accuracy 0.1 K
Limits of calibration errors
± 0.1 K (25°C to 45°C)
± 0.2 K (other)
Minimum necessary
measurement time
1 min
Maintenance interval Every 2 years (as part of the safety checks)
-28 Temperature (optional)
Caution!
Only use the recommended YSI probes of the 400 series or probes that are
compatible with those. Any accessories other than those itemised in the ‘list of
approved accessories’ (see chapter 9.8 Approved Accessories, Spare Parts and
Consumables, p. 224) are not permitted.
A certification of biocompatibility according to ISO 10993-1 is required.
Capnometer (optional, capONE Nihon Kohden)
Description/explanation
Operation principle Semi quantitative measurement with infrared technology:
This measurement mode is based on the assumption that the
inhalatory air mixture does not contain any CO
2
.
Displayed parameters CO
2
-concentration as filled waveform (capnogram)
CO
2
-value (EtCO
2
)
respiratory rate
Measuring quantity CO
2
partial pressure
Measurement range 0 to 100 mmHg
0 to 13.33 kPa
Display resolution 1 mmHg
0.13 kPa
Measurement interval Continuous
Measurement mode Optical in mainstream mode (also suitable for sidestream
applications)
Standby time (warm-up phase) Approx. 5 sec.
Response time Approx. 120 msec.
Operating temperature range 0 - 45 °C
Barometric pressure 70 - 106 kPa
Relative humidity 30 - 95% (without condensation)
Calibration Automatic continuous self calibration;
no manual calibration necessary
Interface to sensor Type BF, defibrillation-proofed (EN 60601-1; IEC-601-1)
Sensor size (H x W x D) 22 mm x 11 mm x 11 mm
Sensor weight (with cable) < 40 g
