User Manual corpuls
3
Appendix
ENG - Version 2.1 – P/N 04130.2 297
Description/explanation
Test According to EN 1060-1 and EN 1060-3,
Non-invasive blood pressure instruments, part 1 and part 3
-26 Non-invasive blood pressure measurement module (Option NIBP, manufacturer
SUNTECH)
Caution!
Only use the recommended NIBP-cuffs and hoses. Any accessories other than those
in the ‘list of approved accessories’ (see chapter 9.8 Approved Accessories, Spare
Parts and Consumables, p. 224) are not permitted.
Invasive Blood Pressure Measurement Module IBP (Option)
Description/explanation
Amplifier Type CF, insulated > 5 kV, defibrillation proof
Number of interfaces 2 x 2 (4 channels at 2 interfaces)
Transducer sensitivity
5 µV/V/mmHg
Upper limit frequency 20 Hz
Scanning frequency 100 Hz per channel
Digital definition 0.5 mmHg/Bit
Measuring range -50 to 300 mmHg
Display range ( in mmHg) Negative display range
-10 to 10, -20 to 20, -30 to 30, -40 to 40, -50 to 50
Positive display range
0-30, 0-60, 0-120, 0-180, 0-300
Accuracy The combined effects of sensitivity, repeatability, non-linearity,
drifts and hysteresis are within ± 4 % of the reading taken or
± 0,5 kPa (± 4 mmHg), whichever is bigger.
Validation Medanco
®
Mediserve 200
-27 Invasive blood pressure measurement module IBP (Option)
Caution!
Only use the recommended blood pressure transducers. Any accessories other
than those itemised in the ‘list of approved accessories (see chapter 9.8 Approved
Accessories, Spare Parts and Consumables, p. 224) are not permitted.
Temperature (Option)
Description/explanation
Amplifier Type BF, insulated > 5 kV, defibrillation proof
Temperature sensor YSI 401D (rectal and oesophageal), manufacturer: YSI
company
Measurement iteration 12 measurements per second
Display range
12°C to 50°C
