Appendix
User Manual corpuls
3
296 ENG - Version 2.1 – P/N 04130.2
Description/explanation
Accuracy of pulse rate
measurement
± 4/min.
-25 Oximeter (Option SpO
2
, SpCO, SpHB, SpMet, manufacturer Masimo, Masimo
®
technology
Caution!
Only use the recommended sensors and intermediate cables. Any accessories other
than those itemised in the ‘list of approved accessories’ (see chapter 9.8 Approved
Accessories, Spare Parts and Consumables, p. 224) are not permitted.
Non-invasive Blood Pressure Measurement Module NIBP (Optional,
manufacturer Sun Tech Medical, Inc.)
Description/explanation
Application field Adults, children, neonates and premature infants
Measuring method Oscillometrical principle
Measuring range Adults and children:
systolic: 40 to 260 mmHg
diastolic: 20 to 200 mmHg
MAP: 26 to 220 mmHg
Neonates:
systolic: 40 to 130 mmHg
diastolic: 20 to 130 mmHg
MAP: 26 to 110 mmHg
Measuring interval during
automatic measurement
1, 2, 3, 5, 10, 15, 30, 60 min. duration between the start of two
measurements
Measurement Automatic/manual
Output Application part Type BF
Pressure sensor Semi conductor sensor
Measuring range of pressure
sensor
Up to 300 mmHg
Pressure decrease rate > 3 mmHg/sec.
Maximum inflation pressure adults Adjustable in configuration dialogue up to 280 mmHg
Factory settings at 180 mmHg
Maximum inflation pressure
children
Adjustable in configuration dialogue up to 170 mmHg
Factory settings at 120 mmHg
Maximum inflation pressure
neonates
Adjustable in configuration dialogue up to 140 mmHg
Factory settings at 90 mmHg
Resolution of display 1 mmHg
Display accuracy
Systematic deviation: ± 5 mmHg
Standard deviation: ≤ 8 mmHg
(in the range of 15°C to 25°C and an air humidity of 20% to
85%)
Maximum delay time until alarm < 1.5 sec.
