The following are defined as shockable rhythms:
• ventricular fibrillation
• ventricular tachycardia, rate > 180/min
ECG database for validation of the analysis software
The ECG data used originate from recordings from the AHA Database CD ROM
Series 1.
Application on validation of the analysis software
A total of 1392 measurements from ECG sections which constitute a
representative cross-section of all ECGs have been included for validation of
the analysis software.
According to AHA recommendation, the data records are divided into three
classes. A further class of different rhythms was not included in the
measurements owing to irregularities.
Classification of the Data Records
Rhythms Number By
Shockable Coarse ventricular
fibrillation (amplitude more
than 200 µV)
388 (total) AHA annotation
Rapid VT (r > 180/min) Among others
with an
implanted pacer
AHA annotation
Not
shockable
NSR 1004 (total) AHA annotation
AF, SB, SVT, heart block,
idioventricular, PVCs
Including
approx. 80%
with pathological
characteristics
AHA annotation
Asystole Among others
with an
implanted pacer
Measurement
amplitude:
Peak to peak
< 150 µV
Indefinable Fine ventricular fibrillation 97 Measurement
amplitude:
Peak to peak
< 350 µV
Other VT Measurement
r < 180/min
Not taken into
account
Div. -- Observation of
the ECG
Determination
of irregularities
-36 Classification table
Range of the
measurements
