General Operating Instructions User Manual corpuls
3
58 ENG - Version 2.1 – P/N 04130.2
Accessory Position
Temperature sensor (item 1) Outermost pocket
NIBP cuff (item 2)
Wide elastic band at the side of
outermost pocket
CO
2
sensor (item 4) Left-hand pocket on central section
CO
2
intermediate cable (item 3) Right-hand pocket on central section
CO
2
adapter, mainstream (item 5) Elastic band below the patient box
interfaces
corPatch CPR sensor
Inner pocket
corPatch CPR intermediate cable
Inner pocket
Table
4-4 Contents of right-hand bag
Fig. 4-28 Contents of right-hand bag (illustration may differ)
Only connect the temperature sensor to the patient box after attaching it to the
patient to avoid false alarm messages that indicate excessively low temperature.
Right-hand bag
Note
