Start and Stop of the Recording
Status of the recording operation
It can be determined from the background color of the screen and lighting state of the START/
STOP LED.
Screen background Operation status
Gray (no character):
(START/STOP LED: Off)
• Recording is stopped.
• These settings can be changed.
Yellow (WAITING):
(START/STOP LED: Blinking)
• Recording is in standby.
• This screen is shown from the time the
[START/STOP] key is pressed until the
recording actually starts.
• During repeated recording, this screen is
also displayed when recording is stopped.
• These settings can not be changed.
Green (RECORDING):
(START/STOP LED: On)
• Recording is in progress.
• These settings can not be changed.
START/STOP LED
