Configuration Parameter Definitions
Tuning Parameters Set Up Group
100 DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
4.7 Tuning Parameters Set Up Group
Introduction
Tuning consists of establishing the appropriate values for the tuning constants you are using so that your
recorder responds correctly to changes in process variable and setpoint. You can start with predetermined
values but you will have to watch the system to see how to modify them. There are two Tuning groups
available.
Tuning group prompts
Table 4-6 lists all the function prompts in the Tuning 1 and Tuning 2 setup group and their definitions.
Table 4-6 Tuning group prompt definitions
Upper Display
Range of Setting or Selection
FUZZY OVERSHOOT SUPPRESSION FEATURE
DISABLE—Disables fuzzy overshoot suppression
ENABLE—The recorder will use fuzzy logic to suppress
or mimimize any overshoot that may occur as a result of
the existing tuning parameters. It does NOT change the
parameters.
ACCUTUNE II—On demand tuning algorithm
DISABLE—Disables ACCUTUNE II
ENABLE—TUNExOFF will be displayed as a status
message. Use the Increment or Decrement key to
toggle status to TuneON. New PID parameters will be
entered automatically when tuning is complete.
ACCUTUNE ERROR CODES (Read Only)
