Operation - Monitoring Your Recorder
Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 125
April 2017
Viewing the operating parameters
The upper display is a six-character display, four of which show the value of the PV during normal
operation.
 The lower display is an eight-character display. During normal operation, you can view various
operating parameters. Press the LOWR DISP key to scroll through the operating parameters listed in
66HTable 5-7.
 The lower display shows only those parameters and their values that apply to your specific model and
the way in which it was configured.
 You can configure the lower display to scroll through the items in 67HTable 5-7 at an interval of 1, 2, or 3
seconds. Refer to subsection 3.17 Options Set Up group, function prompt “SCROLL” to make your
selection.
Pressing the LOWR DISP key will freeze the lower display at the presently viewed item; pressing it
again will advance to the next item and scrolling will resume.
 Pressing ▼while pressing LOWR DISP will scroll backwards.
For recorders with two controllers (both enabled) remember that any controller-related values displayed
correspond with the lighted CHN indicator — “1” means that the values apply for Controller #1 and “2”
means that the values apply for Controller #2.
Table 5-7 Lower display key parameter prompts
Prompt
Description
OUT**
Output Value in Percent (%). Note that the output can only be adjusted through the
raise/lower keys when the controller in manual mode.
SP**
Local Setpoint 1. Also current setpoint of SP Ramp or SP Ramp/Soak Program.
SPN
Current setpoint for setpoint rate applications.
2SP**
Local Setpoint 2 (where remote setpoint does not apply)
RSP
Remote Setpoint (when configured)
2IN
Value of Channel 2 input (when available)
DEV
PV deviation from setpoint (±999.9 maximum)
EU
Engineering units that PV represents (when available)
RH
RH value in percent (%) (when available)
PIDSETx**
Tuning Parameter Set x =1 or 2
RAMP
The time (minutes) remaining in the setpoint ramp
#RA
The time (minutes) remaining in the SP Ramp segment
#SK
The time (minutes) remaining in the SP Soak segment
RECYC
The number of recycles remaining to be run in the Setpoint Program
**
Time remaining in Timer function
**
Time elapsed in Timer function
TUNExXXX**
Accutune II indicator.
x = Loop number (1 or 2). XXX = ON or OFF.
