Honeywell DR4500A User Manual

Setpoint Ramp/Soak Programming and Operation - Setpoint Program Event Set Up Group
Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 169
April 2017
To ensure control of relay by segment event
To make sure a segment event operates the associated relay, observe the requirements below.
Table 6-7 Segment event relay operation requirements
Relay
Relay is controlled by (in order of priority)
Requirements for operation of
relay by segment event
1
13. Timer function
14. Alarm 1
 Do not configure Timer.
 Configure Alarm 1 type
Event.
2
Alarm 2
Configure Alarm 2 type Event.
3
15. Controller 1 output algorithms Relay Simplex,
Position Proportional, Relay Duplex,
Current/Relay Duplex
16. Alarm 3
 Do not configure Controller
#1 with these output
algorithms.
 Configure Alarm 3 type
Event.
4
17. Controller 1 output algorithms Position
Proportional, Relay Duplex, Current/Relay
Duplex
18. Alarm 4
 Do not configure Controller
#1 with these output
algorithms.
 Configure Alarm 4 type
Event.
5
19. Controller 2 output algorithms Relay Simplex,
Position Proportional, Relay Duplex,
Current/Relay Duplex
20. Alarm 5
 Do not configure Controller
#2 with these output
algorithms.
 Configure Alarm 5 type
Event.
6
21. Controller 2 output algorithms Position
Proportional, Relay Duplex, Current/Relay
Duplex
22. Alarm 6
 Do not configure Controller
#2 with these output
algorithms.
 Configure Alarm 6 type
Event.
