3.17 Options Set Up Group
Introduction
This data deals with various options that are available with your recorder. If your recorder does not have
any of these options the prompts will not appear.
Function prompts
Table 3-15 lists all the function prompts in the Option Set Up group.
Table 3-15 Options group function prompts
Function Prompt
Lower Display
Function Name
Selections or Range of Setting
Upper Display
Factory
Setting
REJ FREQ
Rejection Frequency
50HZ
60HZ
60HZ
HF REJ
High Frequency Rejection
ENABLE
DISABL
ENABLE
RELHUMID
Relative Humidity
NO
YES
NO
ATMPRES
Atmospheric Pressure
Compensation
590 to 800 mmHg
––
DEVIATION
Deviation Recording Action
NONE
SETPNT
CHAN1
NONE
DEVSETPT
Deviation Setpoint Value
–999.0 to 9999
0
SCROLL
Lower Display Scroll
NONE
1 SEC
2 SEC
3 SEC
NONE
GRANDTOT
Grand Totalizer
ENABLE
DISABL
DISABL
