Chart Set Up Group
Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 65
April 2017
3.8 Chart Set Up Group
Introduction
The functions listed in this group deal with the parameters that must be set to assure proper chart function.
CAUTION
Before making any configuration changes to the Chart Set Up group, place the recorder in
“Chart Hold”. Press the CHART key to stop the chart rotation. Press again after configuration
entry is made.
Function prompts
Table 3-5 lists all the function prompts in the “Chart” Set Up group.
Table 3-5 Chart group function prompts
Function Prompt
Lower Display
Function Name
Selections or Range of Setting
Upper Display
Factory
Setting
CHRTSPD
Chart Speed Selection
8HR
12HR
24HR
7DAYS
XHR (See prompt "HOUR/REV")
XHR
HOUR/REV
Hours per Revolution
(appears only if "XHR" is
selected above)
1 to 744
12
LINEARIZ
Linearization
LINEAR
NONLIN
––
