Honeywell DR4500A User Manual

Installation - Mounting Methods
Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 19
April 2017
Reference data for existing panel cutouts
Refer to Table 2-4 to determine whether the existing panel cutout can be used. Use the procedure for
mounting with the universal filler kit unless otherwise noted.
Table 2-4 Reference data for mounting DR4500A in existing panel cutouts
Manufacturer / Instrument
Dimensions of Existing
Panel Cutout (inches)
Need Universal Filler
Plate Kit
30755134-001 Blue Color
30755134-002 Gray Color
Honeywell/Model AR100*, DR4200
12.7 x 12.7
No*
Honeywell/Class 15
15.8 x 17.2
Yes
Honeywell/Class 45
13.12 x 17.12
Yes
Badger Meter/Model Micro Chart
14.25 x 17.88
Yes
Bristol/Models 4330, 500 Classes 1, 2A, 3B, and 5
3.56 x 18.56
Yes
Fisher and Porter/Model 51-1100
13.75 x 17.31
Yes
Foxboro/Model 40
14.38 x 17.06
Yes
Kent/Model 105M**
13.6 x 13.46
No**
Partlow/Model ER*
13.5 x 12.69
No*
Taylor/Model 76J
13.78 x 16.5
Yes
*No adaptation is required, use procedure for “Flush in Panel - New Panel Cutout”
**Use procedure for “Cutout made for Kent Model 105M”
Adapter plate dimensions
The dimensions of the adapter plate (part number 30755134) are 16.5” x 19”.
