142 DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
5.11 Alarm Setpoints
Introduction
 An alarm consists of a relay contact and an operator interface indication. The alarm relay is de-energized
if Alarm Setpoint 1 or Setpoint 2 is exceeded.
 The alarm relay is energized when the monitored value goes into the allowed region by more than the
hysteresis.
 There are twelve alarm setpoints, two for each alarm.
 The type and state (High or Low) is selected during configuration: see Section 3 - Configuration for
details.
ATTENTION
An active alarm will always provide an indication on the display but may not control the relay;
that is, a higher priority function such as a control loop or timer may have control of the relay.
Procedure for displaying the alarm setpoints
The procedure for displaying and changing the alarm setpoints is listed in 83HTable 5-25.
Table 5-25 Procedure for displaying or changing the alarm setpoints
Step
Operation
Press
Action/Result
1
Access the Alarm Set Up
group
SET
UP
Until you see:
Upper Display: SET UP
Lower Display: ALARM X
X = 1, 2, 3, 4, 5, 6
2
Access the Alarm
Setpoint Values
FUNC
Successively displays the alarm setpoints and their
values.
Upper Display: The alarm setpoint value
Lower Display: AXS1 VAL – Setpoint 1 value of
alarm 1, 2, 3, 4, 5, or 6
AXS2 VAL – Setpoint 2 value of
alarm 1, 2, 3, 4, 5, or 6
▲ or ▼
Change any alarm setpoint value you select in the
upper display.
3
Return to normal
operation
LOWR
DISP
Returns to normal operation.
