Installation - Mounting Methods

Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 23

April 2017

Pan Head Screw

8-32 x 3/4 inch

Hex Head Bolt

1/4-20 x 5/8 inch

Hex Head Bolt

1/4-20 x 5/8 inch

Bracket (4)

Side View

NOTE: Mounting brackets, attaching hardware, and panel gasket are included in kit 30755065-503;

Slot

8-32 x 3/4 inch

Pan Head Screw

Hex Head Bolt

1/4-20 x 5/8 inch

Slot

Figure 2-8 Panel Mounting Recorder with NEMA4X Door
